Aalborg OS-TCi
Destinada a un uso auxiliar, la Alfa Laval Aalborg OS-TCi es una caldera marina de combustión para la producción de vapor. Diseñada con tubos helicoidales que proporcionan una mayor superficie de transferencia de calor que las soluciones convencionales, ofrece una eficiencia que permite ahorrar combustible. Preparada para la transición de combustibles, la OS-TCi puede utilizar aceites, biocombustibles y un combustible alternativo de su elección.
Caldera de combustión con autolimpieza, con opciones multicombustible e híbridas
- Genera entre 1200 y 8000 kg/h de vapor con un alto rendimiento energético
- Mantenga la eficiencia y ahorre combustible gracias a la tecnología TCi (Turbo Clean, inteligente) de autolimpieza de la caldera
- Cuente con un tiempo de actividad sin interrupciones, garantizado gracias a un diseño robusto y a un sistema de control intuitivo
- Impulse la descarbonización adaptando el sistema a los combustibles alternativos que elija
- Aprovecha la conexión a la red eléctrica o el excedente de electricidad a bordo mediante el funcionamiento híbrido
Con su eficaz sistema de autolimpieza, el Aalborg OS-TCi es una opción preparada para el futuro que te permite pasar al GNL, al metanol o al amoníaco cuando te resulte más conveniente. Las opciones híbridas y preparadas para híbridos contribuyen a su configuración flexible.
La Aalborg OS-TCi es una caldera de combustión para uso marítimo diseñada teniendo en cuenta la descarbonización y la transición energética. Además de funcionar con los combustibles actuales, incluidos los de bajo contenido en azufre, los biocombustibles y el GNL, está diseñada para ser compatible con el metanol y otros combustibles de bajas emisiones que irán apareciendo con el tiempo. El concepto de «caldera preparada» de Alfa Laval ofrece una plataforma preparada para el futuro, lo que permite ajustar el quemador y la sección de presión de la caldera existentes según sea necesario.
Independientemente del combustible que se utilice a bordo, la Aalborg OS-TCi permite ahorrar combustible gracias a su excepcional eficiencia térmica y a la tecnología TCi (Turbo Clean, inteligente) de autolimpieza. El proceso de limpieza TCi, que favorece la eficiencia y garantiza una larga vida útil de la caldera, es automático, aunque también se puede activar manualmente.
Multi-fuel capabilities
The Aalborg OS-TCi supports multiple decarbonization strategies. Built on a fuel-flexible boiler platform, it can operate on oils and biofuels – and be configured for an additional alternative: LNG, methanol or ammonia.*
*Ammonia solution in development
Hybrid operation with electricity
As well as supporting multiple fuels, the Aalborg OS-TCi can be configured as a hybrid boiler for electric operation. This lets you cut direct emissions by taking advantage of shore power or surplus electricity on board.
Future-proof conversion options
If you aren’t ready for an alternative fuel or hybrid capability today, the Aalborg OS-TCi can still be prepared. New boilers can be delivered multi-fuel-ready and/or hybrid-ready, making later conversion easy and cost-efficient.
High-efficiency helix tubes
The helix-shaped design of the Aalborg OS-TCi tubes increases the heat transfer area, which means fuel-saving efficiency. An internal baffle forces the steam to pass through the tube bundle twice, ensuring absolutely dry steam.
Self-cleaning boiler technology
The Aalborg OS-TCi features TCi (Turbo Clean, intelligent) self-cleaning technology, which keeps the boiler running efficiently and prolongs its service life. The TCI cleaning process is automatic, but it can also be initiated manually.
LNG safety options
When using LNG, the Aalborg OL can take on additional functions. The boiler can safely combust boil-off gas (BOG) or free flow from the LNG tank, as well as the mix of inert gas and methane created before and after tank inspection.
